FY-CBK-120 hose pressing machine is famous for its intelligent
control system and large opening mouth. With a super crimping
force, it can crimp hydraulic hose R15 R13 up to 2 inch.
MAIN FEATURES
1. Thin head, easy fed for bend fitting;
2. Big crimping power;
3. High accuracy.
crimping range/skiving range | 6-76mm(1/4''-3''inner diameter of hose) |
quantity of dies | 15 sets |
item diesNo. of | length 60mm(15,19,23,26) |
Length 70mm(31,36,41) |
Length 80mm(47,55,60) |
accuracy | 0.01mm |
output volume of pump | 10L/16L |
system pressure | 31.5Mpa |
motor power | 5.5kw |
voltage | 380V |
crimping force | 1500T |
work efficiency | 300pcs/h |
maximum open diameter | 158mm |
the max open tolerance | ±53mm |
package dimension | 1050*850*1680mm |
machine dimension | 1000*800*1630mm |
Net weight | 1250kg |
Gross weight | 1300kg |
The features of big range rubber hose crimping machine
1.Easy operating and portable
2.Fast speed and high efficiency
3.Low noise and low maintenance cost
4.High quality and favourable price
5.Durable and stable
6.Long life for using
7.Have a large range of crimping
8.Suitable different pressure of hoses
9.Have big power
Kindly reminder
1.Before using the machine,pls read and take care of the manual
operation .
2.Pls confirm that the voltage coincide with the standard of ours
3.Don’t allow children,elderly people and the disabled to touch even make
use of the machine.
4.When the machine go out of service,pls turn off the power source.
How to Crimp the Ends on a Hydraulic Hose?
1 Insert one end of a length of hydraulic hose into the hydraulic
hose fitting. Make sure it is securely in place.
2 Set the micrometer on the hose-crimping machine according to
manufacturer specifications for the kind of hose and fitting you
are using. Find these specifications in the hose-crimping machine's
manual.
3 Place the fitting end of the hose into the crimping machine and
line up the fittings mark on the machine with the top of the hose.
4 Insert the compression ring into the crimping machine.
5 Activate the hosecrimping machine.
The crimping machine's press will exert pressure on the compression
ring, causing the compression mechanism to press against the
hydraulic hose fitting and crimp it in place.6 Repeat this process with the remaining end of the hydraulic hose
The attention about the big range rubber hose crimper machine
1.Motor start:Pay attention to the direction of rotation of the
motor and pump rotation direction or arrow direction.
2.Before the operation:Check the hydraulic oil tank .
3.Normal operation:For the first 30 minutes please do the running
after normally begin to use the machine
4.Hydraulic oil:No any regulation for oil spill valve,the highest
pressure must not exceed the rated pressure .Pressure hazard!Danger
of injury.
5.System failure:If system failure happen,do not blindly
process.Please in accordance with the operation manual or sequence
analysis to deal with the problems or find professional repair
engineer to solve problems.
